Circuit board factory: Which kinds of rigid circuit boards are classified
Kim 0 Comments

Circuit board factory: Which kinds of rigid circuit boards are classified

Keyou circuit according to the circuit layer classification: divided into single panel, double panel and multi - layer board. The common multilayer board is generally 4 or 6 layers, complex

Multilayer board can reach dozens of layers. There are three main types of PCB boards:

This type of board has wiring on both sides, although to use both sides it must be in between

A proper electrical connection will do. This "bridge" between circuits is called a pilot hole (via). A pilot hole is a small hole in a PCB that is filled or coated with metal,

It can be connected to the wires on both sides. Because the area of the dual panel is twice as large as that of the single panel, the dual panel solves the problem of the single panel because of the wiring interleaving

Difficult (can be through the hole to the other side), it is more suitable for use in more complex circuits than a single panel.


To increase the area that can be wired, Multi-Layer Boards use more single or double-sided wiring boards. With a piece

Printed circuit boards with two sides for the inner layer and two single sides for the outer layer or two sides for the inner layer and two single sides for the outer layer are bonded by positioning system and insulation

A printed circuit board with alternating materials and interconnected conductive patterns as required by design becomes a four - or six-layer printed circuit board, also known as a multilayer

Printed circuit board.


The number of layers of the board does not mean that there are several independent wiring layers. In special cases, empty layers will be added to control the thickness of the board. Usually, the number of layers is even, and

And contains the outermost two layers.

Most of the main board is 4 to 8 layers of structure, but technically theory can be done close to 100 layers of PCB board. Large supercomputers are mostly

A considerable number of layers of mainframe boards are used, but since such computers can be replaced by clusters of many ordinary computers, super multi boards are becoming less common

It was used. Because the layers in the PCB are so tightly integrated, it's not always easy to see the actual number, but if you look closely at the host board, it's still

You can see that.
