Common materials for SMT patch processing are introduced
Caddy 0 Comments

Common materials for SMT patch processing are introduced

SMT SMT processing customers are very concerned about the processing quality, the quality of SMT processing is the top priority, but for SMT OEM material selection of electronic components is also one of the key factors affecting product quality. Electronic processing is inseparable from electronic components, the selection of components is also one of the core issues, not only to ensure the quality of products, but also to control the cost within the budget, quality and cost balance. The following professional SMT processing factory kingford to give you a brief introduction to SMT patch processing of some common components.

SMT patch processing common materials

1. Patch resistance

Resistance is an electronic component with resistance characteristics, which is widely used in SMT patch processing. Resistors are divided into fixed resistors and variable resistors (potentiometers), which play the role of voltage balancing, shunt and current limiting in the circuit.

2. Patch capacitance

Capacitor is also one of the basic components of SMT processing. It is a storage unit for electrical energy. It performs coupling, filtering, DC and tuning functions in electronic circuits.

3. Induction coil

This is what we call an inductance, which stores magnetic energy. Inductor in SMT machining is usually composed of frame, winding, shield cover, iron core and so on. The resistance of the potentiometer can be changed. In SMT process, the resistance needs to be adjusted continuously within the specified range, called potentiometer. The potentiometer is composed of a shell, a sliding end, a rotating shaft, a ring resistor and three lead ends.

4. Transformer

A transformer is generally composed of an iron core and a coil, which has two or more windings, of which the winding connected to the power supply is called a primary coil, and the rest is called a secondary coil. When there is AC current in the primary coil, AC flux will be generated in the magnetic core, making the voltage induction in the secondary coil. Transformer is mainly used for AC voltage conversion, current conversion, power conversion, impedance conversion and buffer isolation.

5. Crystal diode

The crystal diode is composed of PN junction, electrode lead and additional sealed shell, which has unidirectional conductivity.

6. Field effect transistor

This diode is also a PN junction semiconductor device. Unlike transistors, it does not take advantage of the electrical conductivity of the PN junction in chips machined by SMT, but of its insulating properties.
