Rogers RT5870 High Frequency Board

RT/duroid® 5870 and 5880 glass microfi ber reinforced PTFE composites are designed for exacting stripline and mi crostrip circuit applications.

Glass reinforcing microfi bers are randomly oriented to maximize benefi ts of fi ber reinforcement in the direc tions most valuable to circuit producers and in the fi nal circuit application.

The dielectric constant of RT/duroid 5870 and 5880 laminates is uniform from panel to panel and is constant over a wide frequency range. Its low dissipation factor extends the usefulness of RT/duroid 5870 and 5880 to Ku-band and above.

RT/duroid 5870 and 5880 laminates are easily cut, sheared and machined to shape. They are resistant to all solvents and reagents, hot or cold, normally used in etching printed circuits or in plating edges and holes.

Normally supplied as a laminate with electrodeposited copper of ¼ to 2 ounces/ ft.2 (8 to 70μm) on both sides, RT/duroid 5870 and 5880 composites can also be clad with rolled copper foil for more critical electrical applications. Cladding with aluminum, copper or brass plate may also be specifi ed.

When ordering RT/duroid 5870 and 5880 laminates, it is important to specify dielectric thickness, tolerance, rolled or electrodeposited copper foil, and weight of copper foil required.
