PCB circuit board factory to share the main causes of PCB board explosion and prevention countermeasures

The main reasons for PCB board bursting (popcorn) are the following two categories: ① sheet water absorption ②α2/z-CTE is too big, and the board water absorption caused by bursting board accounts for 70% of the defects. Other reasons include PCB structure uneven growth and contraction, uneven cooling and heating, process injury and bad blackness... Although we can not rule out the possibility, but the rate is not high.


Why "water" is the main cause of PCB board burst?


The "water" has little effect on the bursting plate below 100°C.


When the temperature exceeds 100°C, the "water" becomes the resin's plasticizer.


If the resin absorbs more water, Tg will decrease (△Tg should be less than 5°C) and the rubber state will come earlier, it will cause instant Swelling (Swelling) in the Z direction of the plate and rapid cracking (it is most likely to happen between 100°C and Tg). Refer to the top chart of the article, the pressure (psi) after the water vapor exceeds 100°C will increase in proportional series.


Generally, the CTE(expansion coefficient) of X and Y plates is relatively stable, between 15 and 16ppm/°C. In addition, the hidden water in the plate will also become plastic resin, and the external water together to help Zhou.


When the resin temperature exceeds the Tg point, it will change into rubber state. At this time, the "water" part of the explosive plate has become a supporting role, and at this time, most of the water has been evaporated into steam. Moreover, the rubber state is soft, and it is not easy to have explosive plate.

pcb

Where does the PCB "water" come from?


Since the "water" is so important to the explosion plate, then we have to study where the water comes from, on our general understanding and cognition, most of the "water" may come from the outside world, may be in the PCB process inhalation attachment, or PCB storage from the environment gradually Diffusion (Diffusion) into; But the internal structure of the plate is easy to hide water is also one of the possible reasons; Another thing you might not expect is that PCB resins also have water molecules embedded in their formula, which, when heated, creates its own water. So in summary, the plate absorbs "water" and the water storage place is:


Water is the structure of resin molecules themselves (molecules of similar polarity already have water molecules in them, and whenever there is OH in the formula it will form).


Resin and glass fiber interface is easy to hide water (the board uses a resin and a glass fiber woven with warp and weft, if the weaving is not dense enough, there will be gaps, it is generally recommended to choose low permeability flat fiber cloth is not easy to hide water).


Resin and copper foil interface is also easy to hide water.


The holes in the plates will hold water.


PCB absorbent explosion board improvement program - baking


Since "water" is the main cause of board explosion, so as long as the PCB water removal should be able to solve most of the board explosion problem, and [baking] is the best way to remove the PCB external water. Since the purpose of baking is to remove moisture, the baking conditions are best to meet the following requirements:


Heat the oven to a temperature just above 100°C (105°C is recommended, because the oven temperature is not correct) so that the water can escape as steam.


When baking, it is best to separate each board, so that the moisture is more easily volatilized. If PCBS overlap, water will not escape as effectively.


The oven must have an exhaust device, otherwise it is useless to bake the oven full of steam.


From the selection of PCB board and the process to control the water absorption conditions


Although baking is the best way to improve the burst board, baking not only wastes time, but also wastes equipment and manpower, and the Tg value will decrease after baking PCB is also a problem. A better method is to control the water absorption conditions from the selection of PCB board and the manufacturing process.


If the plate itself has polarity, it is easy to absorb water. Try to choose not absorbent resin to prevent the plate from absorbing water.


Open (flat) fabric can be used. Reduce the gap between resin and glass fiber interface to reduce the possibility of easy water storage. (The following picture is only a schematic, not the real glass fiber cloth, basically by the warp and weft two strands of material staggered woven, if there is a gap between the warp and weft, it is easy to hide water, so generally to check the tightness of the tightness, the better the tightness, the smaller the breathability, the less easy to hide water, the high-frequency circuit board is also relatively no loss and signal equal one problem.)


The picture is only a schematic diagram, not the real glass fiber cloth, basically by the warp and weft two strands of material staggered woven, if there is a gap between the warp and weft, it is easy to hide water, so generally with air permeability to check its tightness.
