Common defects and preventive measures of RCF type pcb milling cutter in production
Kim 0 Comments

Common defects and preventive measures of RCF type pcb milling cutter in production

RCF type pcb milling cutter is the most common type of milling cutter in printed circuit board processing, and it is also the most common type of milling cutter produced by pcb milling cutter enterprises. However, due to some of its defects, the product yield in the production process is reduced, making the production cost higher, so what is the cause of the defects and how to control the defects are the problems we should pay attention to.

1. Wrong blade shape

Edge type error refers to the inconsistency between the rcf type pcb milling cutter and the requirements, such as the requirement that 6 left-handed blades are required, but the actual processing is only 5 left-handed blades, so that the pcb milling cutter produced is completely a waste product, and for example, the requirement is that the rcf type pcb milling cutter is required to open the fishtail mouth, but the actual did not open.

Reason: The main reason for this defect is that the production operator does not strictly implement the process procedures in the production process, such as less opening a left-handed blade is caused by the carelessness of the process personnel when looking at the drawing.


Preventive measures: Process personnel and production operators must carefully review the product drawings, calculate each parameter in the product, and strictly in accordance with the standards of product drawings to produce, you can eliminate such defects.

2. Blade breakage

The criterion for determining the edge of RCF type pcb milling cutter is that the blade notch is greater than or equal to 1/2 of the edge depth or edge width value, or the opening is seriously broken and has multiple edge phenomenon.

Reasons: The main reasons for the breakage of RCF type pcb milling cutter are as follows:

1) In the process of unloading the tool to the plate, the error in the horizontal direction of the unloading manipulator and the plate hole exceeds the tolerance range, resulting in collision between the two and causing the rcf type pcb milling cutter to produce a collapsing edge defect.

2) rcf type pcb milling cutter in the transfer, cleaning, testing and packaging and other operations, due to the staff's mistakes lead to the tool and other hard objects collision resulting in the collapse of the edge.

Preventive measures:

Accurately adjust the error accuracy of the two to ensure that the two will not interfere in the work;

In the transfer of packaging and other links, the principle of light handling is strictly implemented to ensure that the tool is not hurt.
