Welding resistance film design skills

In fact, no matter what type of PCB designsoftware you prefer to use, soldering masks are optional. The welding mask can be easily designed by completing the filling of a few parameters. Some software even offers automatic welding of masks.


Prior to the actual design, it is essential to contact a contracted PCB manufacturer to properly understand their capabilities in terms of the thickness of the welded mask and the minimum spacing between the brazing pads, which are not cured per plate.


Boards will fail due to silly problems with welding masks (such as not enough openings, too many openings, and a mismatched number of openings to the brazing pads in the circuit plane). These problems can result from negligence or design document changes, but they do take a long time. Some even cause disasters. Therefore, your design document is well worth a close look.

Understand the difference between aluminum substrate and pcb board

What is aluminum substrate


Aluminum substrate is a kind of metal base copper-covered plate with good heat dissipation function. Generally, a single panel is composed of three layers, which are circuit layer (copper foil), insulation layer and metal base layer. Common in LED lighting products. There are positive and negative sides, the white side is welded LED pin, the other side shows aluminum color, generally coated with thermal coagulation and thermal part contact. There are ceramic substrates and so on.

What is a PCB board


PCB board generally refers to printed circuit board. Printed circuit board {PCB circuit board}, also known as printed circuit board, is the electrical connection provider of electronic components. It has a history of more than 100 years; Its design is mainly layout design; The main advantage of using circuit board is to greatly reduce wiring and assembly errors, improve the level of automation and production labor rate.

pcb

According to the number of layers of the circuit board can be divided into single panel, double panel, four layer board, six layer board and other multilayer circuit boards. Because the printed circuit board is not a general terminal product, so in the name of the definition is slightly confused, for example: personal computer with the mother board, called the motherboard, but not directly called the circuit board, although there is a circuit board in the host board, but not the same, so the evaluation of the industry about the two can not say the same. Another example: because there are integrated circuit parts on the circuit board, so the news media called it IC board, but it is not the same as printed circuit board. What we usually refer to as a printed circuit board is a bare board - a circuit board with no components on it.

Aluminum substrate and pcb board difference


For some just engaged in the aluminum substrate industry partner will always have such a question, that is, what is the difference between aluminum substrate and pcb board, in view of this question below Xiaobian on the specific to tell you what the difference between the two in the end?


pcb board and aluminum base board are designed in accordance with the requirements of pcb board. At present, aluminum base pcb board in the market is generally single-sided aluminum base board, pcb board is a large type, aluminum base board is only a type of pcb board, aluminum foundation board, because of its good thermal conductivity, generally used in the LED industry.


Generally speaking, pcb board is copper substrate, which is also divided into single panel and double panel, the material used between the two is very obvious difference, aluminum substrate is the main material of aluminum plate, and pcb board is the main material of copper. Aluminum substrate because of its PP material special. The heat dissipation is better. The price is also more expensive


Compared with the two in heat dissipation, the performance of aluminum substrate in heat dissipation is more superior and pcb board, its thermal conductivity is not the same. Aluminum substrate is a kind of PCB, and the price of aluminum substrate is more expensive.
