How should industrial control circuit board be repaired

A circuit board is composed of circuit boards, components and software. In my opinion, the ability of maintenance personnel and maintenance tools such as detection are very important when repairing circuit boards. Modern circuit board if only rely on a person's experience and lack of necessary tools to maintenance is difficult to do, only advocate online tester and other testing equipment and do not pay attention to the quality of personnel is also difficult to do. Industrial circuit board maintenance when you face the board is not the same as the treatment method is not the same. But the basic idea is to find out what's broken and replace it and fix it. Why don't we just replace every component on the board that we can? I have tried to change even after, some components need to be debugged, pay attention to the overall effect. With online tester and other tools like mine scanning, each component made a mark check again, compare the VI curve. This can find some faults but not always fix the board, "because the chip passed by the online tester is not necessarily broken; A chip that passes the test is not necessarily undamaged." And not every component can be found in the component library, machine circuit boards are constantly updated and upgraded, so your detection tools should be constantly updated.

 1 (26)

The quality of maintenance personnel directly affects the success or failure of maintenance. In the absence of any schematic diagram, to maintain a relatively unfamiliar industrial control circuit board, in addition to profound hardware skills, it needs to be a maintenance engineer who has a good understanding of the circuit principle and structure. When he sees a strange circuit board, he should carefully observe the hardware structure to determine the role of this board. Ask the customer what machine the board is mounted on when The Times what kind of warning. When judging the role of a circuit board, it is necessary to construct a block diagram of the circuit board in the mind, and the information analysis from the alarm is that the link is faulty.



Industrial control circuit board maintenance, the staff's approach is also very important, repair circuit board is a very fine work with a lot of components and circuit boards and easy to damage, so the operation should be very careful to need the necessary fixtures and other auxiliary tools. Disassembly, welding and so on to be skilled in not to start to think about the whole operation process, to avoid unnecessary damage. For the program of the chip, can back up as far as possible, do not allow backup do not move. If it is found that there is a program chip damage, and can not find a spare or replacement chip that the circuit board can not be repaired.



Maintenance in addition to finding the broken things to repair, the most difficult is to test whether they have repaired and on the machine debugging, no matter how you are repaired, the end to be installed on the machine tool can be used, and sent to the customer's hand circuit board must be good, which is not sent out before the machine test, my company purchased a large number of maintenance test bench, and according to the customer's board simulation production test, To ensure that the circuit board delivered to the customer can be used normally, without delay in production.
