The method of rational layout of components in PCB design
Kim 0 Comments

The method of rational layout of components in PCB design

First, beauty should not only consider the orderly placement of components, but also consider the beautiful flow of the line.

Because the general layman sometimes more emphasis on the former, in order to one-sided evaluation of the advantages and disadvantages of circuit design, in order to the image of the product, the former should be given priority when the performance requirements are not harsh. However, in high-performance occasions, if you have to use dual panels, but also packaged in the inside, usually can not see, you should prioritize the beauty of the line.


Second, the force circuit board should be able to withstand various external forces and vibrations during installation and work.

Therefore, the circuit board should have a reasonable shape, and the positions of various holes (screw holes, special-shaped holes) on the board should be reasonably arranged. Generally, the distance between the hole and the edge of the plate should be at least greater than the diameter of the hole. At the same time, it should also be noted that the weakest section of the plate caused by the special-shaped hole should also have sufficient bending strength. In particular, the connectors that directly "extend" out of the equipment housing on the board should be reasonably fixed to ensure long-term reliability.


For high-power, serious heating devices, in addition to ensuring heat dissipation conditions, but also pay attention to placing in the appropriate position.


Especially in sophisticated analog systems, special attention should be paid to the adverse effects of the temperature field generated by these devices on the fragile pre-amplifier circuit. Generally, the part with very large power should be made into a module separately, and certain thermal isolation measures should be taken between the signal processing circuit.


Fourth, signal interference is the most important factor to consider in PCB layout design.


The most basic aspects are: the weak signal circuit and the strong signal circuit are separated or even isolated; The AC part is separated from the DC part; The high frequency part is separated from the low frequency part; Note the direction of the signal line; Layout of ground wire; Appropriate shielding, filtering and other measures. All these have been repeatedly emphasized in a large number of discussions, and will not be repeated here.


Installation refers to a series of basic requirements put forward in the specific application in order to smoothly install the circuit board into the chassis, shell, and slot, without space interference, short circuit and other accidents, and make the specified connector in the designated position on the chassis or shell.
