Analysis of the cause of bubbling on copper plating surface of PCB circuit board
Kim 0 Comments

Analysis of the cause of bubbling on copper plating surface of PCB circuit board

The bubbling of the circuit board is actually the problem of poor binding force on the board, and by extension, the surface quality of the board, which contains two aspects: 1. The cleanliness of the board; 2. Surface micro-roughness (or surface energy) problem; The bubbling problem on all circuit boards can be summarized as the above reason. The adhesion between the coatings is poor or too low, and it is difficult to resist the coating stress, mechanical stress and thermal stress generated in the production and processing process and assembly process in the subsequent production and processing process, resulting in different degrees of separation between the coatings. Server PCB


Some factors that may cause poor quality of the board in the process of production and processing are summarized as follows:


1. Problems of substrate processing; Especially for some thin substrate,(generally 0.8mm below), because the rigidity of the substrate is poor, should not be used to brush the plate, this may not be able to effectively remove the substrate production and processing process to prevent copper foil oxidation and special treatment of the protective layer, although the layer is thin, brush plate is easier to remove, but there are greater difficulties in chemical treatment, Therefore, in the production and processing of important attention to control, so as not to cause the poor bonding force between the substrate copper foil and chemical copper caused by the bubbling problem; This problem in the thin inner layer of blackening, there will also be bad blackening brown, uneven color, local black brown is not superior problems.


2. The surface of the board in machining (drilling, laminating, milling, etc.) process caused by oil or other liquids contaminated with dust pollution surface treatment phenomenon,


3. Copper sinking brush plate is bad: copper sinking before grinding plate pressure is too large, resulting in orifice deformation brush out orifice copper foil fillet and even orifice leakage substrate, so that in the process of copper plating, tin spraying and welding will cause orifice foaming phenomenon; Even if the brush plate does not cause leakage of the substrate, but the heavy brush plate will increase the roughness of the copper orifice, so in the process of micro-etching coarsening, the copper foil is easy to produce excessive coarsening phenomenon, there will be a certain quality hazard; Therefore, attention should be paid to strengthen the control of the brush process, the brush process parameters can be adjusted to the best through the wear mark test and water film test;


4. Washing problem: Because copper plating treatment to go through a large number of chemical potion treatment, all kinds of acid, alkali, organic and other drugs more solvent, the board washing is not clean, especially copper adjustment oil removal agent, not only will cause cross pollution, but also cause the board local treatment of poor or poor treatment effect, uneven defects, resulting in some binding force problems; Therefore, attention should be paid to strengthen the control of washing, including the control of water flow, water quality, washing time, and plate dripping time, etc.; Especially in winter, the temperature is low, the washing effect will be greatly reduced, more attention should be paid to the strong control of washing; Automotive sensor PCB


5. Micro-etching in copper plating and graphic plating pretreatment; Excessive micro-erosion will cause the hole leakage substrate, resulting in bubbling around the hole; Insufficient micro erosion will also cause insufficient binding force, causing foaming phenomenon; Therefore, the control of microerosion should be strengthened. Generally, the corrosion depth of copper deposition before treatment is 1.5- 2 microns, and that of graphic electroplating before treatment is 0.3- 1 micron. If possible, it is best to control the corrosion thickness or corrosion rate by chemical analysis and simple test weighing method. Under normal circumstances, the surface of the micro corrosion after bright color, uniform pink, no reflection; If the color is not uniform, or reflective indicating that there is a quality hazard before processing; Pay attention to strengthen inspection; In addition, the copper content of the micro-etching tank, the temperature of the tank, the load, the content of the micro-etching agent, etc., should be paid attention to;


10. Copper plating pre-leaching tank should pay attention to timely replacement, too much pollution in the tank, or too high copper content, will not only cause the cleanliness of the board, but also cause rough surface defects;


12. In addition, in winter, when the tank liquid in some factories is not heated, special attention should be paid to the live into the tank of the production process, especially the plating tank with air stirring, such as copper nickel; For nickel cylinder in winter, it is best to add a warm water bath before nickel plating,(the water temperature is about 30-40 degrees), to ensure that the initial dense nickel layer deposition is good;


In the actual production process, there are many reasons for the surface bubbling, the author can only do a brief analysis, for different manufacturers of equipment technical level may appear different reasons caused by the bubbling phenomenon, the specific situation to be specific analysis, not generalize, copy rigid; The analysis of the above reasons is not primary, secondary and important, basically according to the production process to do a brief analysis, in this series, just to provide you with a direction to solve the problem and a broader vision, the specific situation according to the site situation.
