From the perspective of PCB product segmentation structure, common multilayer board occupies the mainstream position of PCB products. In 2021, the global PCB market will be multi-layer board accounting for 38.6%, single and double panel accounting for 11.6%. The second is the packaging substrate, accounting for 17.6%; Flexible plate and HDI plate accounted for 17.5% and 14.7% respectively. With the rapid development of electronic circuit industry technology, terminal application products show the trend of miniaturization and intelligence, the market demand for high density, high multilayer, high-tech PCB products will become more prominent, high multilayer board, HDI board, packaging substrate and other products with higher technical content will grow faster, and the proportion in the PCB industry will be further increased in the future.

2023-04-18 18:03:44 Shenzhen Saifu Circuit Technology Co., LTD

First, PCB (printed circuit board) industry development overview

Printed circuit board (PCB) refers to the use of printing technology, on the insulation substrate according to the predetermined design of the formation of conductive circuit graphics or printed components of the functional board, used to achieve the mutual connection between electronic components and relay transmission, is an indispensable basic component of electronic information products.

PCB variety is rich, according to the softness of the substrate can be divided into rigid board (R-PCB), flexible board (FPC), rigid and flexible combined board; According to the number of layers of the conductive diagram, it can be divided into single panel, double panel, multi-layer board; In addition, there are special product categories, such as high speed high frequency board, high density connection board (HDI), packaging substrate, etc.

PCB classification

Looking back at the history of PCB, after Charles Ducas successfully printed circuit pattern on the insulating substrate in 1925, after continuous technological progress and upgrading, in 1961 Hazeltine Corporation in the United States produced multilayer board. Since the 21st century, High density BGA, packaging substrate and so on have been rapidly developed.

Development history of PCB

Ii. PCB (printed circuit board) industry laws, regulations and policies

PCB is an essential basic component in modern electronic equipment, is an important part of all kinds of electronic machine products, and plays a key role in the electronic information industry chain. The electronic information industry is a strategic, foundational and guiding pillar industry of the national economy, which is of great strategic significance to the development and security of the national economy. Therefore, the competent authorities of China and the industry have launched a series of industrial policies to support and encourage the PCB industry.

Major laws, regulations and policies of PCB (printed circuit board) industry from 2017 to 2021

Third, PCB (printed circuit board) industry chain

PCB is a bridge that carries electronic components and connects circuits. It plays the role of connection and bearing. It is irreplaceable in the whole electronic products and is known as the "mother of electronics". The upstream of PCB industry chain mainly includes the production of glass fiber cloth, copper foil, epoxy resin and other raw materials and the production of copper clad plate; The middle reaches are PCB manufacturing links; Downstream is the production of all kinds of electronic products, including communications, consumer electronics, automotive electronics, industrial control, YI therapy, aerospace, semiconductor packaging and other fields.

PCB industry chain

The downstream application of PCB is very wide. In 2021, the important downstream application of the global PCB industry is the communication field, accounting for 32%. It was followed by the computer industry at 24 percent. Then there is consumer electronics, with 15 per cent.

2021 Global PCB downstream application field structure

Fourth, the global PCB (printed circuit board) industry status

The manufacturing quality of PCB products directly affects the reliability of electronic products and the overall competitiveness of system products, so PCB is called "the mother of electronic system products". To some extent, the development level of PCB industry reflects the development speed and technical level of a country or region's electronics industry. In recent years, the global output value of PCB has shown an overall growth trend. According to statistics, the output value of the global PCB industry reached $80.9 billion in 2021, with a year-on-year growth of 24.08%.

Scale and growth of global PCB output value from 2014 to 2021

From the perspective of PCB product segmentation structure, common multilayer board occupies the mainstream position of PCB products. In 2021, the global PCB market will be multi-layer board accounting for 38.6%, single and double panel accounting for 11.6%. The second is the packaging substrate, accounting for 17.6%; Flexible plate and HDI plate accounted for 17.5% and 14.7% respectively. With the rapid development of electronic circuit industry technology, terminal application products show the trend of miniaturization and intelligence, the market demand for high density, high multilayer, high-tech PCB products will become more prominent, high multilayer board, HDI board, packaging substrate and other products with higher technical content will grow faster, and the proportion in the PCB industry will be further increased in the future.
