- PCB Design Capabilities
| PCB Design&Layout Capabilities | |||
| Min.trace width: | 2.5mil | Min.trace spacing | 2.5mil |
| Min.Vias: | 6mil(4mil laser drilling) | Max.layer | 48L |
| Min.BGA spacing | 0.35mm | Max.BGA Pin | 3600pin |
| Max.high-speed signal | 40 GBPS | Fastest delivery time | 6 Hours/ Item |
| HDI Highest layer | 22 L | HDI Highest layer | 14 L any layer HDI |
| PCB Design&Layout lead time | |||
| Number of pins on the board | 0-1000 | Design lead time (working days) | 3-5 days |
| 2000-3000 | 5-8 days | ||
| 4000-5000 | 8-12 days | ||
| 6000-7000 | 12-15 days | ||
| 8000-9000 | 15-18 days | ||
| 10000-12000 | 18-20 days | ||
| 13000-15000 | 20-22 days | ||
| 16000-18000 | 22-25 days | ||
| 18000-20000 | 25-30 days | ||
| Ultimate delivery capacity | 10000Pin/7 days | ||
| PS: The above delivery date is the regular delivery date, and the accurate design delivery date needs to be comprehensively evaluated according to the number of components, difficulty, layers and other factors of the circuit board! | |||
Kingford
Why choose us?
Self-organized development
Self-developed tool software and strict quality control system to ensure a successful one-time board opening
difficult design
The maximum design scale is 90000pin, which can provide HDI/Any layer PCB design, 3D PCB design, RF design, 56G high-speed design, etc.
High-quality design quality system
With a strict quality system process and a strict review system, we have zero error rate quality requirements for PCB design.
Professional design team
PCB design team with an average of more than 12 years of work experience, with complete design software, such as Cadence Allegro\ORCAD, Mentor WG\PADS, etc.
Kingford
Our PCB&PCBA Solutions
Kingford
Goldfinger PCB Design FAQ
Excellent electrical conductivity due to direct board connection and more gold thickness, strong wear resistance allows the PCB to be plugged and unplugged thousands of times, and the PCB pads use a hard gold plating process with good oxidation resistance.
Raised corners, nicks, scratches, sink (spots) and tin stains, oxidation, exposed copper or exposed nickel, spot copper shavings, test pin spots.
