|PCB Design&Layout Capabilities|
|Min.trace width:||2.5mil||Min.trace spacing||2.5mil|
|Min.Vias:||6mil(4mil laser drilling)||Max.layer||48L|
|Min.BGA spacing||0.35mm||Max.BGA Pin||3600pin|
|Max.high-speed signal||40 GBPS||Fastest delivery time||6 Hours/ Item|
|HDI Highest layer||22 L||HDI Highest layer||14 L any layer HDI|
|PCB Design&Layout lead time|
|Number of pins on the board||0-1000||Design lead time (working days)||3-5 days|
|Ultimate delivery capacity||10000Pin/7 days|
|PS: The above delivery date is the regular delivery date, and the accurate design delivery date needs to be comprehensively evaluated according to the number of components, difficulty, layers and other factors of the circuit board!|
System advanced training, from beginners to experts, there are various technical special trainings every week.
Self-developed tool software and strict quality control system to ensure a successful one-time board opening
Parallel design to shorten lead time, conventional can shorten PCB design time by 50%
The maximum design scale is 90000pin, which can provide HDI/Any layer PCB design, 3D PCB design, RF design, 56G high-speed design, etc.
With a strict quality system process and a strict review system, we have zero error rate quality requirements for PCB design.
PCB design team with an average of more than 12 years of work experience, with complete design software, such as Cadence Allegro\ORCAD, Mentor WG\PADS, etc.
High-standard confidentiality measures, signing confidentiality agreements, and all documents exporting must be approved to ensure that 100% of documents are not leaked.
we provide 24-hour service and support, you will receive a reply to your question within 2 hours and a quotation within 24 hours.
Amplifier modules, also known as amplifier boards, are PCB (printed circuit board) modules that have audio amplifier chips.
